Effects of Vertical Wall Barrier on The Rigid Pavement Deflection of Full Scale 1-Pile Row Nailed-Slab System on Soft Sub Grade

Puri, Anas and Suhendro, Bambang and Rifa’i, Ahmad (2017) Effects of Vertical Wall Barrier on The Rigid Pavement Deflection of Full Scale 1-Pile Row Nailed-Slab System on Soft Sub Grade. International Journal of GEOMATE, 12 (32). pp. 25-29. ISSN 2186-2982

[img]
Preview
Text
GEOMATE 25-29-6577-Anas-April-2017-32-g1.pdf - Published Version

Download (548kB) | Preview

Abstract

The weaker part of rigid pavement when it is loaded is the edge of slab. Vehicle wheels thatare often running in/out from/to pavement can cause void in the sub base-pavement interface for a long time loading period. Flexural moment caused by temperatures also precipitate the damages of pavement edge. To avoid the damage of pavement edge, the vertical wall barrier is added. This research is aimed to learn the contribution of vertical wall barrier on the pavement of Nailed-slab System to reduce the slab deflection. Full scale observation was done over models in soft clay soil. The full scale of 1 pile row Nailed-slab System was conducted on soft clay which consisted of 6.00 m x 1.20 m slab area with 0.15 m in slab thickness, 5 short micro piles as slab stiffeners which were installed under the slab. Piles and slab were connected monolithically, then in due with vertical concrete wall barrier on the two ends of slab. The system was loaded by compression loadings on the slab. Deflection of model without vertical wall barrier was analyzed by finite element method. Results show that the vertical wall barrier cannot significantly reduce the deflection for edge loading. It is opposite to the model test result from Puri, et.al. (2011) where the vertical wall barrier can reduce 74% deflection for edge loadings. It is to be expected that numerical application program could not model the vertical wall barrier which lower position than slab level.

Item Type: Article
Uncontrolled Keywords: rigid pavement, soft clay, Nailed-slab System, vertical wall barrier, deflection
Subjects: T Technology > TA Engineering (General). Civil engineering (General)
Divisions: > Teknik Sipil
> Teknik Sipil
